Built for shooting versatility, the Sightmark T-5 is a magnifier that mounts behind a reflex sight or red dot and provides an absolute co-witness. Instantly change the magnification of your close-range optic from 1x to 5x by using the T-5s flip-to-side mount. The magnifiers streamlined, low drag design prevents it from snagging on clothing and equipment and makes the T-5 .7 shorter than the magnifier its replacing. Ideal for stretching your AR engagements out to 200 yards, an included LQD mount allows for rapid attaching/detaching in intense shooting situations. The T-5s aluminum construction is shockproof up to .308 caliber rifles and provides IP55 water resistant protection. Brightness and resolution are improved from fully multi-coated optics and external windage and elevation adjustments help shooters align the reticle of their red dot/reflex sight to the center of the magnifiers point of view. The Sightmark T-5 includes flip-to-side LQD mount, adjustment tools and manual. Eotech and Aimpoint compatible.
Check out the entire range of products from Sightmark.
| Width: | 2.60" |
| Windage Elevation: | Adjustable |
| Diopter Adjustment: | +3/-3 |
| Weight: | 10.90 oz |
| Includes: | T-5 Magnifier/Flip to Side Mount/Mounting Hardware |
| Material: | Aluminum |
| Eye Relief: | 2.25"/57mm |
| Field of View: | 9.8 M at 100 M |
| Tube Diameter: | 30 mm |
| Height: | 1.67" |
| Model: | T-5 Magnifier 5X with Flip to Side Mount |
| Firearm Type: | Rifle/AR Platform |
| Magnification: | 5x |
| Exit Pupil Diameter: | 4.60 mm |
| Proofs: | Water Resistant/Shockproof |
| Optic Coating: | Fully Multi Coated |
| Length: | 4.72" |
| Objective: | 23 mm |
| Color: | Matte Black |
| Mount Type: | Picatinny Rail |
| Series: | Magnifier |
